Tethered Neural Recording System

Product Code: 33

Our T-Series tethered headstage systems are capable of acquiring and filtering up to 32 individual signals, with a 1:1 channel to wire ratio. However, we recommend the M-Series amplifier systems for tethered applications requiring very high channel counts and minimal wiring.

All T-Series recording headstages provide a compact and reliable connection to your electrodes. These headstages interface perfectly with our data acquisition equipment, but they are also adaptable and can output analog data directly to other amplifier systems.

You may choose to integrate these products with an existing data acquisition system or as a total solution package with everything you need to get your project started, including data acquisiton hardware and software. The tethered headstages are available with your choice of gains 2, 20, 100, and 1000. The default headstage connectors are 25 or 50 mil Omnetics, and we frequently accommodate custom connectors.
Features:
Tethered headstage of choice throughout the electrophysiology research community
Standard Omnetics connectors on input (electrode) and output
Choice of electrode interface boards for various species and applications
800x system gain (requires base station) for optimal signal to noise ratio (factory configurable)
Available with digital output to NeuroWare, analog output or both
Video LED tracking available with optional OptiMap video tracking software
NeuroWare and OptiMap datasets easily exportable to MatLab, NeuroExplorer, or EDF

Configurations:
T8 System
Record up to 8 data channels plus 1 reference channel
Custom VLSI circuit provides small size and reduced weight
Available with gain of 2, 20, and 100
Unity gain ground buffer output
Selectable bandpass filtering per channel
+/- 1.65V/+/- 2.5V operation
Headstage dimension: 12x12x5mm (Gain 2), 19x11x5mm (Gain 20,100)
Headstage weight: < 0.9 grams
T16 System
Record up to 16 data channels plus 1 reference channel
Custom VLSI circuit provides small size and reduced weight
Available with gain of 2, 20, and 100
Unity gain ground buffer output
Selectable bandpass filtering per channel
+/- 1.65V/+/- 2.5V operation
Headstage dimension: 15x8x3mm (Gain 2), 20x9x3mm (Gain 20,100)
Headstage weight: < 0.75 grams
T32 System
Record up to 32 data channels plus 2 reference channel
Custom VLSI circuit provides small size and reduced weight
Available with gain of 2, 20, and 100
Unity gain ground buffer output
Selectable bandpass filtering per channel (Gain 20, 100)
Bandwidth is DC to 48 kHz
+/- 1.65V/+/- 2.5V operation
Headstage dimension: 15x14x3.6mm (Gain 2), 20x14x3mm (Gain 20,100)
Headstage weight: < 0.8 grams
